Nylon Tying Machine – (NT – 999)

Description

The Nylon Tying Machine – (NT – 999) is used by pedal. Automatically move the cable ties to the position of the jaws. Automatically collects the waste material into waste tank. The binding force would be more accurate and stable than the electronic measure and converting system. The tightening force and residual tail are set by adjusting screws.

Features
  • PLC control to ensure the stability of each procedure
  • The whole operation takes only 1.2 sec
  • The time belt length can be adjusted and set through HMI
  • The winding laps and speed can be adjusted and set through HMI
Applications

It is applicable for home appliances, automobile industry, and tele communication.

Technical Details
Operating Interface Touch Screen (HMI) With PLC
Power Supply 220V AC 50/60 Hz
Power 1500 W
Pneumatic Pressure Not Required
Cable tie Specification (Width X Thickness) 1.8 x 0.8 mm
Operation speed 2 to 4 Sec
Dimensions & Weight (L X W X H) 502 X 490 X 585
Weight 30 Kgs
